Our Services

Consult Our Expert Technicians

At AE Mechanical, we provide a variety of high-efficiency commercial heating and cooling products and services. We will find the right option that meets your home needs and your budget. Get in touch with us to learn more about our previous projects and much more.

Heat Check Gas Furnace

Our heat check gas furnaces are clean, affordable, safe, and efficient energy; the wise choice.

Combustion Gas Analysis: Perform analysis testing
Temperature: Record Indoor / Outdoor temperature
Flue: Check condition, pitch, and termination
Drain: Operation – 90% only: Blow out drain trap and mainline (add anti-bacterial tabs)
Safety Switch: Check operation
Voltage: Record High / Low
Grounding: Check equipment is grounded
Wire Harness / Pin Connector: Visual check
Control Board: Check for corrosion, overheating, and loose connections
Capacitor: Check values
Burners: Visual check / clean burners (as needed)
Blower Motor: Check for leaking oil
Blower Motor: Check mounts and oil bearings
Blower Wheel / Motor: Visual check for cleanliness

Filters: Clean / Replace filters (owner supplied filters)
Grills / Registers: Check cleanliness
Thermostat Battery: Replace the battery
Thermostat: Functioning properly and calibrate temperature
Gas Pressure: Check-In / Out gas readings
Heat Exchanger: Perform visual and flame test
Furnace Start: Start furnace and analyze flue gas
Flame Sensor: Check readings before cleaning and after cleaning (3 microamps)
Blower / Inducer Fan: Check motor amp readings
Vacuum Switch Values: Readings before and after cleaning ports and hoses
Temperature Rise: From R/A grill to R/A plenum
Safety Control: Test operation, limits, and rollouts
Furnace: Check sequence of operation
Carbon Monoxide: Check CO2 levels in the house
Static Pressure: Perform test

Heat Check Heat Pump

Explore our heat check heat pumps that are low on cost yet very effective. Our heat pumps are cheaper to run than systems based on combustion.

Temperature: Record Indoor / Outdoor temperature
Wire Harness / Pin Connector: Visual check
Voltage Air Handler: Record High / Low voltage in Air Handler
Control Board: Look for corrosion, overheating, loose indoor unit connection
Capacitor: Check values Indoor unit
Blower Motor: Check motor mounts, oil leakage, amp draw, and cleanliness
Blower Wheel: Visual check for cleanliness
Filters: Clean / Replace filters (owner supplied filters)
Thermostat Battery: Replace the battery

Thermostat: Functioning properly, sequencing and calibrate temperature
Grills / Registers: Check cleanliness
Disconnect: Check Outdoor and Indoor
Voltage Outdoor: Record High / Low voltage in Outdoor Unit
Capacitor: Check values on Heat Pump
Condenser: Check cleanliness
Condenser Fan Motor: Check fan blades condition and motor mounts
Condenser Motor Bearing: Oil fan bearing
Compressor: Check amp draw and inrush amps
Condenser Fan: Check amp draw
Suction Temperature and Liquid Temperature

Refrigerant: Check refrigerant charge, calculate super-heat and sub-cooling temperature
Condenser Coil: Check to enter and to exit air temperature
Reversing Valve: Check operation and temperature values
Defrost: Check to defrost operation
Electrical Heat Element: Check sequencer operation and amp draw
Return Air: From R/A grill to R/A plenum
Air Handler: Check temperature rise. Heat pump and Aux modes
Static Pressure: Perform test

Air Check Air Conditioner

Improve your comfort levels at workspaces and your homes by consulting our technicians, who will enhance your ACs and leave you with a rejuvenating ambiance.

Temperature: Record Indoor / Outdoor temperature
Voltage: Record High / Low at the furnace or air handler
Control Board: Check for corrosion, overheating, and loose connections
Grounding: Check equipment is grounded
Filters: Clean / Replace filters (owner supplied filters)
Wiring Harness / Pin Connector: Visual check
Capacitor: Check values in the furnace or air handler
Blower Motor: Check for leaking oil
Blower Motor: Check mounts and oil bearings
Blower Wheel / Motor: Visual check for cleanliness
Blower Motor: Check amp draw
Evaporator Coil: Check for cleanliness
Drain: Clean/Blow out drain pan, mainline and add tabs

Thermostat Battery: Replace the battery
Thermostat: Functioning properly and calibrate temperature
Grills / Registers: Check cleanliness
Disconnect: Check wiring
Voltage: Record High / Low at Outdoor unit
Capacitor: Check values at Outdoor unit
Condenser: Check for cleanliness
Condenser Fan Motor: Check for oil on the fan motor
Condenser Fan Blades: Check condition and oil condenser motor
Suction Pressure and Head Pressure:
Refrigerant: Calculate super-heat and sub-cooling
Evaporator Coil: Check temperature across coil – Indoor
Temperature Rise: From R/A grill to R/A plenum – Indoor
Static Pressure: Perform test
